The New SPANK HEX DRIVE HUB, featuring:

ALL MOUNTAIN	TRAIL	ENDURO	FREERIDE	DOWNHILL	GRAVEL	XC
✔	✔	✔	✔	✔

SPANK’s HEX DRIVE 102T technology delivers 3.5° engagement, for almost instant pickup

6 independent pawls with 3 steps per pawl, work in unison, meaning 18 engagement points per click

Bite-Block Alloy HG and XD Freehub bodies resist damage from cassettes without the weight penalty of steel

Unique flange design reduces dish requirement and minimizes tension range between drive side and non-drive side spokes

Advanced seal system improves prevention of bearing/drive system contamination

ENGAGEMENT:	HEX DRIVE 102T / 3.5° / 6 Pawl
HOLE COUNT:	32H J-Hook
DISC MOUNT:	6-bolt
MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy freehub body
FINISH:	Matte anodized, laser logos

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy "Bite Block" freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Alloy HG
WEIGHT +/- (g):	318
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Alloy XD
WEIGHT +/- (g):	310
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141

MATERIAL:	CNC optimized forged alloy hub body, alloy axle alloy freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Alloy MICROSPLINE
WEIGHT +/- (g):	322
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy "Bite Block" freehub body
CONFIGUARTION:	12x150mm, J-hook
FREEHUB:	Alloy HG
WEIGHT +/- (g):	323
ADAPTORS INCLUDED:	12X157
ADAPTORS AVAILABLE SEPARATELY:	none

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy "Bite Block" freehub body
CONFIGUARTION:	12x150mm, J-hook
FREEHUB:	Alloy XD
WEIGHT +/- (g):	315
ADAPTORS INCLUDED:	12X157
ADAPTORS AVAILABLE SEPARATELY:	none

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy freehub body
CONFIGUARTION:	12x150mm, J-hook
FREEHUB:	Alloy MICROSPLINE
WEIGHT +/- (g):	327
ADAPTORS INCLUDED:	12X157
ADAPTORS AVAILABLE SEPARATELY:	none

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy "Bite Block" freehub body
CONFIGUARTION:	12x142mm, J-hook
FREEHUB:	Alloy HG
WEIGHT +/- (g):	314
ADAPTORS INCLUDED:	12X135
ADAPTORS AVAILABLE SEPARATELY:	QRX135, 10X135

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy "Bite Block" freehub body
CONFIGUARTION:	12x142mm, J-hook
FREEHUB:	Alloy XD
WEIGHT +/- (g):	309
ADAPTORS INCLUDED:	12X135
ADAPTORS AVAILABLE SEPARATELY:	QRX135, 10X135

HEX J-TYPE FOR E-BIKE:

MATERIAL:	CNC optimized forged Alloy hub body, alloy axle, steel freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Steel HG
WEIGHT +/- (g):	406.5
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, steel freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Steel XD
WEIGHT +/- (g):	395
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141

MATERIAL:	CNC optimized forged alloy hub body, alloy axle, steel freehub body
CONFIGUARTION:	Boost 12x148mm, J-hook
FREEHUB:	Steel MICROSPLINE
WEIGHT +/- (g):	380.5
ADAPTORS INCLUDED:	none
ADAPTORS AVAILABLE SEPARATELY:	Boost QRx141
